Robust & Durable: Featuring a large 1.25″ oversized ball, deep knurling, and heavy-duty knobs, this head is built to withstand the demands of tough environments.
Adaptable Functionality: The ‘Tilt Lock Knob’ allows you to lock the ball into a single axis of motion, converting the head into a pan/tilt style for precise glassing. (see video)
Easy to Use: The main ball lock has an aggressive knurled face and offers a minimum tension set point for quick, intuitive adjustments.
Highly Compatible: The Arca-Swiss dovetail and 3/8″-16UNC base ensure broad compatibility with a wide range of tripods.
Compact & Low Profile: At just 3.2″ tall, this head has a low center of gravity & saves space in your pack without compromising stability.
Specifications
Weight: 12 oz (with Quick Release Plate)
Load Capacity: 35 lb
Height: 3.2″
Base Width: 1.9″
Ball Diameter: 1.25″
Base Socket: 3/8-16 UNC
Material: Anodized 6061-T6 Aluminum
Lockable 360° Panoramic Base
Oversized ball lock knob with minimum tension control
